| Weight | 6 oz |
|---|---|
| Dimensions | 2.25 × 2.25 × 1.71 in |
| Features | • ±0.5 to ±10 g ranges |
| Applications | • Vehicle Testing |
JMA-100/200/300 Analog MEMS Accelerometer Series
Highlights:
Compare
The JMA-100/200/300 series is available in single (JMA-100), dual (JMA-200), and triple (JMA-300) axis configurations. This presents a robust and rugged design for industrial use, but with the benefit of low-cost MEMS technology.
Additional information
