Emico Series 13

Highlights:

Edgewise meters mount vertically or horizontally with a curved (13) or flat (13F) front. 5% Accuracy meters incorporate a moving magnet mechanism. Available size 2″.

Compare
Categories: , Tags: , , ,
Additional information
Dimensions 1.875 × 1.828 × .765 in
Available Inputs

• Available with DC and AC Rectified inputs
• DC: mA, A, V
• AC: mA, A, V
• Plus custom-designed inputs and scales
Downloads

Downloads

Series 13 Outline Drawing
Series 13F Outline Drawing
